Amplifier - Cục đẩy công suất
DUS AP1300
| Rated power／mode | AP1300 |
|
1kHz(HIA)with0.5％THD Roted Output Power 8ohm Roted Output Power 4ohm Roted Output Power 2ohm |
2X1300W 2X1950W 1x3900W |
|
Voitage gain |
100dB |
| Slew Rate(at 1kHz，LPF bypassed) | >10V/us |
| Input Sensitivity(at roted output power or voltage，1kHz) | 0.77V/1.4V /32dB |
|
Total harmonic distortion |
0.5％ |
|
Frequency Response |
20Hz～25kHz,+0/-1dB |
|
Input impedance(balanced) |
balanced 20kΩ,unbalanced 10kΩ |
|
Damping Factor(8ohms)10Hz-400Hz Signal to Noise ratio (A weighted) |
>200 >100dB |
| Power Cord Specifications | plug:10A,250V; wire:3xl0mm2 |
| Power requirements | 200—240V～50-60Hz |
| Slze(unit:mm) | 483x270x66mm |
| Net weight | 14kg |
Sản phẩm cùng loại
Amplifier Dus Audio AL1000
mota
Power output: 2700W
8Ω stereo: 2 x 1000W
4Ω stereo: 2 x 1350W
8Ω bridged mono: 2700W
Frequency Response: 20Hz - 20KHz
THD: =/<0.35％
S/N Ratio: >100dB
Xem thêm
Amplifier Dus Audio AL700
mota
Power output: 1980W
8Ω stereo: 2 x 700W
4Ω stereo: 2 x 990W
8Ω bridged mono: 1980W
Frequency Response: 20Hz - 20KHz
THD: =/<0.35％
S/N Ratio: >100dB
Xem thêm
Amplifier Dus Audio AL500
mota
Power output: 1500W
8Ω stereo: 2 x 500W
4Ω stereo: 2 x 750W
8Ω bridged mono: 1500W
Frequency Response: 20Hz - 20KHz
THD: =/<0.35％
S/N Ratio: >100dB
Xem thêm
